1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly

Good quality stainless steel braided hose for sales
Good quality stainless steel braided hose for sales
I'm Online Chat Now

1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly

China 1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly supplier
1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly supplier 1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly supplier 1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly supplier 1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly supplier

Large Image :  1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly

Product Details:

Place of Origin: CHINA
Brand Name: QDGY
Certification: TS16949,ISO9001,DOT SAE J1401,FMVSS106
Model Number: GSG111

Payment & Shipping Terms:

Minimum Order Quantity: 1000
Price: negotiation
Packaging Details: 200 into cartons
Delivery Time: within 30 days
Payment Terms: T/T,L/C
Supply Ability: 90000000
Contact Now
Detailed Product Description

1/8 rsize dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly

1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly



-- Product Description ---                                 www.qdgybrakehose.com

1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly

1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly

 Rubber Brake Hose Specifications:

Inner Diameter Outer Diameter Outer layer Double braid Inner layer
1/8"    (3.2mm) 0.413"  (10.5mm) EPDM PVA EPDM
3/16"  (4.8mm)

0.492"     (12.5mm)

 Rubber Brake Hose Features:

  • Two braid PVA reinforced hose
  • Meets FMVSS-106 and SAE J1401 specifications
  • Every brake hose pressure tested to 3500 psi( 240 bar or 24Mpa )
  • Burst pressure:minimum 7250 psi ( 500 bar or 50Mpa )
  • Temperature range -50°C to 121 °C
  • Compatible with DOT3,DOT4 and DOT4+ brake  fluides

Rubber Brake Hose Advantages:

  •  Built to DOT and SAE automotive industry quality and safety standards.
  •  Hoses constructed of EPDM rubber and PVA braid, offering high dynamic strength and chemical & thermal resistance

  •   Brake Hoses with banjo end fittings are packaged with new copper washers to assure proper sealing.

  •   Brake Hoses tested up to 4,000 PSI without rupture based on burst test

Application:

For use in braking system of the vehicle.



 Technical Specification:                                    www.qdgybrakehose.com

Test Items
Test Condition
Standard
Test Results
ID
Normal
3.2mm
3.15~3.45mm
OD
Normal
10.5mm
10.30~10.70mm
Expansion
1000psi
0.33cc/ft max.
0.14~0.16cc/ft
1500psi
0.42cc/ft max.
0.20~0.22cc/ft
2900psi
0.61cc/ft max.
0.41~0.43cc/ft
Burst

4000psi×2min;pressure rated 25,000±10,000psi/min

>7000psi No seepage
>10,500psi
Whip
235~250psi
>35h
>70h
Tensile
tensile speed:218±3mm/min
>1446N
2400N
Cold Bend
-45°C ~-48°C× 72h, 3-5s,bending180°
No cracking
No cracking
Ozone
100pphm×70h×40°C, 7X
No cracking
No cracking
Impulse
146°C 1±0.1min at 1600psi+70
>7000psi No crack
>7500psi
Compatibility
120°C × 70h
>7000psi No seepage
>8800psi
Salt Spray
5%NaCl, 24h,water cleanout in 35°C
No red rust
No red rust
Water Aging
Water in 85±2°C,after 70h~72h 4000psi × 2min;pressure rated 25,000±10,000psi/min
>7000psi; >35h; >1446N
>10250psi;>60h; >2200N


Related Products

 Relate Product :                                              www.qdgybrakehose.com

1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly

Packaging & Shipping

Packaging:                                          www.qdgybrakehose.com

QDGY common package:  PVC bag in carton box with QDGY logo

Welcomed special package request,single packing,tasteful degined package are ok.Only little cost of special package.



Lead time:                                               www.qdgybrakehose.com

For fitting:  common fitting within 30 days;special fitting within 40 days.

For brake hose:  wihithin 20 days.

For brake hose assembly:  within 40 days.

Please noted:  Exact lead time is based on details order ,please contact with us for the details information.

Shipping:                                                 www.qdgybrakehose.com

Qingdao port(Chingtao port) is only about 30 minitues from our factory.

Qingdao airport is only about 40 minitues .

Conveniently by air or by ocean with cheaper freight fee.

Company Information

 ---COMPANY INFORMATION---                                  www.qdgybrakehose.com

1/8 size dot OEM approved SAE J1401 FMVSS106 standard rubber brake hose assembly

Qingdao Guosong Machinery Parts Co.,Ltd first began brake hose & fitting & assembly operations in China in 1996.The premier OEM's rely on the service ,quality and performance of the brake hose assemblies.QDGY has the capability to design and provide complete validation testing to the customers requirements.

We offer the most comprehensive assortment of brake hoses and PA and plating coated steel line in the industry. In addition, we offer a complete line of fittings and unions to complete the job.







QDGY factory is the professional manufacturer of rubber brake hose,stainless steel braided brake hose,all kinds of fitting,brake hose assembly,bundy tube,and all kinds of accessory.

SAE J1401 brake hose:

3.2x10.5mm rubber brake hose

4.8x12.5mm DOT approved brake hose

brake hose:

3.2x7.5mm -3AN braid brake hose

3.2x6.5mm stainless steel braid brake line

4.8x8.0mm -4AN brake line

Steel tube:

3/16" steel pipe

1/4" bundy pipe

3/8" bundy tube

5/16" steel tube..single wall bundy tube

OE No. rubber brake hose assembly, brake line kits,bundy tube assembly

Accessory:

Rubber accessory,steel accessory,plasitc accessory.

Welcome to visit our website:www.qdgybrakehose.com

FAQ

                          ------   FAQ   -----

Q1:  Waht kinds of main rubber hose can product?

 A:   Rubber brake hose,EPDM brake hose,Hydraulic brake hose,Hydraulic hose,water hose,fuel& oil hose,Brake hose,Stem hose,SAE J1401 brake hose,DOT 1/8" brake hose,stainless steel braided brake hose, brake hose, s.s braided brake hose,OE No. brake hose,Flexible brake hose,Performance competition brake hose...

Q2:  What size of brake hose can you supply?

  A:   common size: 3.2x10.5mm(1/8");4.8x12.5mm(3/16")

        Special size: 3.2x11mm...or your request size

Q3:  Can you print the words(line) as our requirement?

  A:   Yes,we do provide embossed and printing marking with different color ,as your requirement.

Q4:  What kinds of fitting can product?

  A:   All kinds.Female fitting,male fitting,banjo fitting,adepter brake hose fitting,bolts and nuts,steel with zinc ,chrome,nickle...stainless steel,brass...

Q5:  How many types of brake hose do you product?

  A:  Brake hose, braided brake hose,PTFE stainless steel braided brake line,Steel tube,Bundy tube,Steel tube assembly,Brake hose assembly...

Q6:  What is my order's delivery date?

   A:  It usually takes 5-40 days,which generally depends on your order quantity and our storage.Details information ,kindly please feel free to contact with us,or visit our website www.qdgybrakehose.com,we will reply you within 24 hours.
