dot approved SAE J1401 flexible brake hose

Good quality stainless steel braided hose for sales
Good quality stainless steel braided hose for sales
I'm Online Chat Now

dot approved SAE J1401 flexible brake hose

China dot approved SAE J1401 flexible brake hose supplier

Large Image :  dot approved SAE J1401 flexible brake hose

Product Details:

Place of Origin: China
Brand Name: QDGY
Certification: TS16949,ISO9001,SAE J1401,FMVSS106
Model Number: GSG111

Payment & Shipping Terms:

Price: NEGOTIABLE
Packaging Details: 200METERS PER CARTON
Delivery Time: within 15days
Payment Terms: T/T,L/C
Supply Ability: 9000,000 meters per month
Minimum Order Quantity: 500meters
Detailed Product Description

TS16949 control dot approved sae j1401 brake hoses

dot approved SAE J1401 flexible brake hose

dot approved SAE J1401 flexible brake hose

Hose Discription

dot approved SAE J1401 flexible brake hose

Rubber Brake Hose Specifications:

Inner DiameterOuter DiameterOuter layerDouble braidInner layer
1/8" (3.2mm)0.413" (10.5mm)EPDMPVAEPDM
3/16" (4.8mm)

0.492" (12.5mm)

Rubb Brake Hose Features:

  • Two braid PVA reinforced hose
  • Meets FMVSS-106 and SAE J1401 specifications
  • Every brake hose pressure tested to 3500 psi( 240 bar or 24Mpa )
  • Burst pressure:minimum 7250 psi ( 500 bar or 50Mpa )
  • Temperature range -50°C to 121°C
  • Compatible with DOT3,DOT4 and DOT4+ brake fluides

Application:

For use in braking system of the vehicle.

Technical Specification:

Test Items
Test Condition
Standard
Test Results
ID
Normal
3.2mm
3.15~3.45mm
OD
Normal
10.5mm
10.30~10.70mm
Expansion
1000psi
0.33cc/ft max.
0.14~0.16cc/ft
1500psi
0.42cc/ft max.
0.20~0.22cc/ft
2900psi
0.61cc/ft max.
0.41~0.43cc/ft
Burst

4000psi×2min;pressure rated 25,000±10,000psi/min

>7000psi No seepage
>10,500psi
Whip
235~250psi
>35h
>70h
Tensile
tensile speed:218±3mm/min
>1446N
2400N
Cold Bend
-45°C ~-48°C× 72h, 3-5s,bending180°
No cracking
No cracking
Ozone
100pphm×70h×40°C, 7X
No cracking
No cracking
Impulse
146°C 1±0.1min at 1600psi+70
>7000psi No crack
>7500psi
Compatibility
120°C × 70h
>7000psi No seepage
>8800psi
Salt Spray
5%NaCl, 24h,water cleanout in 35°C
No red rust
No red rust
Water Aging
Water in 85±2°C,after 70h~72h 4000psi × 2min;pressure rated 25,000±10,000psi/min
>7000psi; >35h; >1446N
>10250psi;>60h; >2200N

dot approved SAE J1401 flexible brake hose

dot approved SAE J1401 flexible brake hose

Related Products

dot approved SAE J1401 flexible brake hose

Packaging & Shipping

Packaging:

QDGY common package: PVC bag in carton box with QDGY logo

Welcomed special package request,single packing,tasteful degined package are ok.Only little cost of special package.

Lead time:

For fitting: common fitting within 30 days;special fitting within 40 days.

For brake hose: wihithin 20 days.

For brake hose assembly: within 40 days.

Please noted: Exact lead time is based on details order ,please contact with us for the details information.

Shipping:

Qingdao port(Chingtao port) is only about 30 minitues from our factory.

Qingdao airport is only about 40 minitues .

Conveniently by air or by ocean with cheaper freight fee.

FAQ

---FAQ---

Q1: Waht kinds of main rubber hose can product?

A: Rubber brake hose,EPDM brake hose,Hydraulic brake hose,Hydraulic hose,water hose,fuel& oil hose,Brake hose,Stem hose,SAE J1401 brake hose,DOT 1/8" brake hose,stainless steel braided brake hose,teflon brake hose,teflon s.s braided brake hose,OE No. brake hose,Flexible brake hose,Performance competition brake hose...

Q2: What size of brake hose can you supply?

A: common size: 3.2x10.5mm(1/8");4.8x12.5mm(3/16")

Special size: 3.2x11mm...or your request size

Q3: Can you print the words(line) as our requirement?

A: Yes,we do provide embossed and printing marking with different color ,as your requirement.

Q4: What kinds of fitting can product?

A: All kinds.Female fitting,male fitting,banjo fitting,adepter brake hose fitting,bolts and nuts,steel with zinc ,chrome,nickle...stainless steel,brass...

Q5: How many types of brake hose do you product?

A: Brake hose,Teflon braided brake hose,PTFE stainless steel braided brake line,Steel tube,Bundy tube,Steel tube assembly,Brake hose assembly...

Q6: What is my order's delivery date?

A: It usually takes 5-40 days,which generally depends on your order quantity and our storage.Details information ,kindly please feel free to contact with us,or visit our website www.qdgybrakehose.com,we will reply you within 24 hours.

Our Services

---Our Service---:

Sample:

Free samples are available by freight collectwithin 7 days.

Warranty:

1.Quality:All products confirm SAE J1401 standard,and100% teseted before shipping.Safe for user.

2.Guarantee:3 years.Any technical problem will under maintenance.

Market:

dot approved SAE J1401 flexible brake hose

Delvery:

Qty/pcs

Delivery Time/day

500~1,000

Within 30 days

1,000~10,000

Within 15 days

More than 10,000

Within 20 days

Company Information

---COMPANY INFORMATION---

dot approved SAE J1401 flexible brake hose

Qingdao Guosong Machinery Parts Co.,Ltdfirst began brake hose & fitting & assembly operations in China in 1996.The premier OEM's rely on the service ,quality and performance of the brake hose assemblies.QDGY has the capability to design and provide complete validation testing to the customers requirements.
